български език (EUR)PTFE-LINED TIP GREY GAUGE 21 0,5″ 50
Product code: 7018256
Ptfe-lined Tip Grey Gauge 21 0.5″ 50 from Nordson with a gauge of 21, a gray colour, a length of 12.7 mm (0.50″), an inner diameter of 0.51 mm (0.020″) and an outer diameter of 0.99 mm (0.039″). It is supplied in packs of 50 pieces. More
Parameters
| Gauge | 21 |
|---|---|
| Color | Gray |
| ID milimeter (inch) | 0.51 mm (0.020″) |
| OD milimetr (inch) | 0.99 mm (0.039″) |
| Length millimeter (inch) | 12.7 mm (0.50″) |
| Material tubing | Stainless steel 304 |
| Material HUB | Polypropylene |
| Thread | Luer Lock |
| Packaging (pcs in box) | 50 |
PTFE lined tip with luer lock. Length 12.7 mm. 0.51 mm. Packaging box 50 pieces. Resists clogging of cyanoacrylates. Use for microdot application.
This product features a gauge of 21, a gray colour, an inner diameter of 0.51 mm (0.020″) and an outer diameter of 0.99 mm (0.039″). It also offers a length of 12.7 mm (0.50″), tubing made of stainless steel 304, a polypropylene hub and a Luer Lock connection. It is supplied in packs of 50 pieces.
Documents and 3D models
3D model
(zip, 509.6 kB)
