български език (EUR)GP TIP GAUGE 14 OLIVE 1,0″ 50
Product code: 7018032
GP Tip Gauge 14 Olive 1.0″ 50 from Nordson with a gauge of 14, an olive colour, a length of 25.4 mm (1.0″), an inner diameter of 1.54 mm (0.060″) and an outer diameter of 1.83 mm (0.072″). It is supplied in packs of 50 pieces. More
Parameters
| Tip Angle | Straight |
|---|---|
| Gauge | 14 |
| Color | Olive |
| ID milimeter (inch) | 1.54 mm (0.060″) |
| OD milimetr (inch) | 1.83 mm (0.072″) |
| Length millimeter (inch) | 25.4 mm (1.0″) |
| Material tubing | Stainless steel 304 |
| Material HUB | Polypropylene |
| Thread | Luer Lock |
| Packaging (pcs in box) | 50 |
General purpose stainless steel dispensing tip 1.0" with luer lock. OD 1.83 mm, ID 1.54 mm. Packaging 50 pieces. Burr-free, polished, passivated stainless steel dispense tips.
This product features a straight tip, a gauge of 14, an olive colour, an inner diameter of 1.54 mm (0.060″) and an outer diameter of 1.83 mm (0.072″). It also offers a length of 25.4 mm (1.0″), tubing made of stainless steel 304, a polypropylene hub and a Luer Lock connection. It is supplied in packs of 50 pieces.
Documents and 3D models
Nordson-EFD-Optimum Poster ENG.pdf
(pdf, 974.3 kB)
3D model
(zip, 59.7 kB)
