български език (EUR)PUMP, 1K, 797PCP, 0.30CC/REV,. FFKM
Product code: 7366004
Continuous volumetric dispensing independent of fluid viscosity and changes in viscosity over time guarantees reliable and repeatable processes.
Nordson EFD 797PCP Series pumps dispense precise fluid volumes from 0.30 ml per revolution in manufacturing applications requiring high levels of process control.
• High fluid volume accuracy and repeatability at ±1%.
• Modular design based on the progressive cavity principle (rotor and stator).
• Continuous sealing prevents fluid shear, pulsation, and compression.
• Ideal for abrasive pastes, filled materials, and UV-cure adhesives.
The 797PCP pump is available in four sizes: 0.01 ml, 0.05 ml, 0.15 ml, and 0.30 ml. More
Nordson EFD 797PCP Series pumps dispense precise fluid volumes from 0.30 ml per revolution in manufacturing applications requiring high levels of process control.
• High fluid volume accuracy and repeatability at ±1%.
• Modular design based on the progressive cavity principle (rotor and stator).
• Continuous sealing prevents fluid shear, pulsation, and compression.
• Ideal for abrasive pastes, filled materials, and UV-cure adhesives.
The 797PCP pump is available in four sizes: 0.01 ml, 0.05 ml, 0.15 ml, and 0.30 ml. More
Parameters
| 1K/2K | Single Component |
|---|---|
| Type | Progressive cavity |
| Series | 797 |
| Wetted material | Aluminium / Stainless steel |
Features and benefits
- Fluid volume accuracy and repeatability of ±1% enables an exceptional level of process control
- Continuous volumetric dispensing independent of viscosity changes
- Programmable suck-back for precise dispensing without dripping or oozing
- Modular design with easy disassembly reduces production downtime
Specifications
| Parameter | Value |
| Dimensions | PCP-0.30: 261.4L x 36.0DIA mm (10.29L x 1.42DIA") |
| Weight | PCP-0.30: 550.0 g (1.2 lb) |
| Rotor speed | 10–150 RPM (depends on maximum motor speed) |
| Flow rate | PCP-30: 0.30–45.0 mL/min |
| Dispense volume per dose | PCP-0.01: 0.30 mL |
| Repeatability | ± 1% |
| Suction valve | 1/8 NPT |
| Outlet | Luer fitting |
| Mounting | M4 |
| Fluid chamber | Anodized aluminum |
| Rotor | 300 stainless steel |
| Stator | FFKM (perfluoroelastomer) |
| Operating temperature | 10–40° C (50–104° F) |
| Warranty | 1 year, limited |
